Dräger Alcotest® 4000

The breathalyser Dräger Alcotest® 4000 offers responsible drivers a reliable way to test their breath alcohol and gives them the assurance of being legal to drive.

This is ensured by precise measurement technology identical to that used by the police: over 30 million breath alcohol tests a year.

Benefit

So that uncertainty doesn’t come along for the ride
Have you already had one glass of wine too many or is your blood alcohol content still in the green? Whether there is still residual alcohol in the body is something that people often find out too late. With the Dräger Alcotest 4000 you can test yourself at any time if you are ready to drive. This way, you can be more relaxed when faced with alcohol checkpoints by police or employer. No residual alcohol, no stress.

Fast and reliable alcohol tester
Whether after a business lunch, at a party or the morning after: Thanks of the DrägerSensor you always obtain a precise result when measuring the residual alcohol value. The measurement function is simply activated with the back-lit function button. Optional audible feedback provides additional orientation. The device is ready to use in seconds and the breath test can be performed immediately. The same button is used to navigate through the menu.

Replaceable mouthpiece
The mouthpiece is intuitive to fit and protected by a cap. A new mouthpiece should be used for each person being tested. Additional mouthpieces are available as accessories. The air channel passes the exhaled air over the device, and only a small sample of this air is drawn for analysis. This ensures that there is no residual alcohol in the device and that all measurements remain precise and reliable. The same method is also used by the police.

Always ready for use
On cool winter nights or a hot summer day: The device is ready for use almost immediately. The temperature range for measurements ranges from -5 °C to +50 °C.

Handy and discreet
Thanks to its compact design, the Alcotest 4000 fits into a trouser pocket. Therefore you can take a measurement discreetly at any time – no matter where you are.

Designed for years of use
The Alcotest 4000 is Made in Germany and meets the highest quality standards. Regular calibration of the device ensures that the measurement technology will remain precise for a long time. The worldwide, regional Dräger service network ensures that you can keep using the device for many years.

Downloads

Drugs & Alcohol Brochure Product Datasheet Product Datasheet - Greek version

Additional Information

APPLICATION Private
SENSOR TECHNOLOGY Dräger Electrochemical Sensor / Fuel cell
DATA STORAGE 400 Tests
DATA READOUT VIA PC No
CHARGING OF RECHARGEABLE BATTERIES IN DEVICE No
PRINT OPTION No
LANGUAGE CONVERSION BY CUSTOMER Yes
MEASURING RANGE up to 2.5 mg/L
DISPLAY Black / White

Technical Data

MEASURING RANGE up to 2.5 mg/L
OPERATING TEMPERATURE -5°C – 50°C
DISPLAY Black / White
CONNECTION PORT Micro USB
TYPE OF BATTERY 1xCR123A
NUMBER OF TESTS FROM FULL BATTERY 1500
PROTECTION CLASS IP52
CALIBRATION INTERVAL 12 months
START UP TIME 4 seconds
ANALYZE TIME AFTER TEST SAMPLE 3 to 25 seconds
RECOVERY TIME TO BE READY FOR NEXT TEST 20 to 120 seconds

Tests Modes

ACTIVE BREATH ALCOHOL TEST Yes
NON-CONTACT BREATH TEST No
PASSIVE BREATH ALCOHOL TEST No
DRÄGER ALCOTEST MOUTHPIECE Yes
DRÄGER ALCOTEST FUNNEL No
DISPLAYED RESULTS Alcohol concentration value will be shown

Approvals

CE SIGN Yes
EU POLICE APPROVAL (EN15964) Yes
EU PRIVATE USE APPROVAL (EN16280) Yes
NHTSA EVIDENTIAL Yes
AUSTRALIA AS 3547:1997 Yes
GERMAN LLOYD Yes
US COAST GUARD Yes
