Additional information
Technical data: Lifting bags up to 25,1 tons lifting capacity
| Characteristics | W 2-12 | W 10-12 | W 17-12 | W 25-12 |
|---|---|---|---|---|
| Size in mm (L x W x H) | 150 x 150 x 25 | 320 x 320 x 25 | 400 x 400 x 25 | 480 x 480 x 25 |
| Insertion height (mm) | 22 | 25 | 25 | 25 |
| Max. lifting height (mm) | 80 | 170 | 220 | 260 |
| Max. lifting capacity (t) | 1,4 | 9,8 | 16,7 | 25,1 |
| Air requirement (l) | 4,5 | 63,4 | 131,7 | 236,0 |
| Weight (kg) | 0,5 | 2,5 | 4,0 | 5,7 |
| Part no. | 1100976 | 1100977 | 1100978 | 1100979 |
Technical data: Lifting bags up to 100,2 tons lifting capacity
| Characteristics | W 41-12 | W 50-12 | W 65-12 | W 80-12 | W 100-12 |
|---|---|---|---|---|---|
| Size in mm (L x W x H) | 610 x 610 x 25 | 670 x 670 x 25 | 760 x 760 x 27 | 840 x 840 x 27 | 930 x 930 x 27 |
| Insertion height (mm) | 25 | 25 | 27 | 27 | 27 |
| Max. lifting height (mm) | 340 | 370 | 410 | 460 | 510 |
| Max. lifting capacity (t) | 41,2 | 50,2 | 65,2 | 80,2 | 100,2 |
| Air requirement (l) | 681,0 | 897,0 | 1010,0 | 1381,0 | 1895,0 |
| Weight (kg) | 9,3 | 11,2 | 15,5 | 19,0 | 23,3 |
| Part no. | 1091389 | 1100980 | 1091391 | 1100981 | 1100982 |
